1000W 12V DC Power Supply - 80A High Current Output for Industrial Equipment, LED Lighting, and CCTV Systems

Product Description

Connect this unit to 110 or 220 Volts AC household power, and it will supply 1000 Watts at 12 Volts DC and 80 Amps. If more than 80 Amps is required, please search for "AmpFlow parallelable power supply" This power supply has been engineered for use with DC motors. Most power supplies designed for use with LED lighting or other electronics will simply shut down when exposed to the high current demands of motors. Built-in current limiting protects the unit from overloads and short circuits. The current limiting feature enables these power supplies to keep functioning through the high-current start-up surges from motors. Current is limited to the rated maximum even when a larger load is called for, (like when a DC motor starts up). Also, inductive loads (like motors) can cause damage to power supplies that are not designed for them. These power supplies also work well in any application where AC line voltage needs to be converted to DC voltage. Other uses include LEDs, HAM radio, and battery charging. Short-circuit and overload protections help these units survive harsh operating conditions. The power supply shuts down temporarily if the temperature, current, or voltage goes beyond the safe operating range, and it starts up again automatically when the condition goes away – no rebooting is necessary. This high-efficiency power supply has an output voltage that is adjustable by plus or minus 10%. It includes an EMI filter to minimize interference with radio signals and a soft-start circuit that reduces the AC inrush current peaks. Every power supply goes through a full-load burn-in test, so no defective unit leaves the factory. This unit meets all the following safety and EMC standards: UL 1950, EN60950, IEC100-3-2, CE, ROHS AmpFlow® power supplies are available in 5V, 12V, 24V, 36V, and 48 Volts at up to 1000 Watts. Search for "AmpFlow power supply" for more choices.
